ASRock Z590M Phantom Gaming 4 10th and 11th Gen ATX Motherboard

Basic Features

Model: Z590M Phantom Gaming 4
Supports 10th Gen Intel Core Processors and 11th Gen Intel Core Processors
Supports DDR4 4800MHz (OC)
8 Phase Power Design
7.1 CH HD Audio, Nahimic Audio

৳ 16,000.00

Out of stock

SKU: 23725 Category: Motherboard Tags: ASRock, ASRock (Intel), Motherboard

Description

Specification

Basic Information
Supported CPU	– Supports 10th Gen Intel Core Processors and 11th Gen Intel Core Processors (LGA1200) – Digi Power design – 8 Power Phase design – Supports Intel Turbo Boost Max 3.0 Technology – Supports Intel K-Series unlocked CPUs
Chipset	Intel Z590
BIOS	– 128Mb AMI UEFI Legal BIOS with multilingual GUI support – ACPI 6.0 Compliant wake up events – SMBIOS 2.7 Support – CPU Core/Cache, GT, DRAM, VPPM, VCCIN_AUX, VCCIO, VCCIO,VCCST, VCCSA Voltage Multi-adjustment
Form Factor	– Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm – Solid Capacitor design
Expansion Slots
PCI	11th Gen Intel Core Processors – 1 x PCI Express 4.0 x16 Slot (PCIE1 10th Gen Intel Core Processors – 1 x PCI Express 3.0 x16 Slot (PCIE1) – 1 x PCI Express 3.0 x4 Slot – 1 x PCI Express 3.0 x1 Slot – Supports AMD Quad CrossFireX and CrossFireX – 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVi (Integrated WiFi/BT)
M.2 Socket	– 1 x Hyper M.2 Socket (M2_1), supports M Key type 2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (Socket M2_1 works with 11th Gen Intel Core processors only) – 1 x Ultra M.2 Socket (M2_2), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
Memory
Type	Dual Channel DDR4 Memory Technology
Slots	4 x DDR4 DIMM Slots
Supported Memory	– 11th Gen Intel Core Processors support DDR4 non-ECC, un-buffered memory up to 4800+(OC) – 10th Gen Intel Core Processors support DDR4 non-ECC, un-buffered memory up to 4600+(OC) – Supports ECC UDIMM memory modules (operate in non-ECC mode) – Supports Intel Extreme Memory Profile (XMP) 2.0
Maximum Memory	Max. capacity of system memory: 128GB
Graphics
Graphics	– Supports 10th Gen Intel Core Processors and 11th Gen Intel Core Processors (LGA1200) – Digi Power design – 8 Power Phase design – Supports Intel Turbo Boost Max 3.0 Technology – Supports Intel K-Series unlocked CPUs
Connector & Ports
HDMI	1 x HDMI Port
USB (s)	– 2 x USB 3.2 Gen2 Ports (10 Gb/s) (ReDriver) (Supports ESD Protection) – 4 x USB 3.2 Gen1 Ports (Supports ESD Protection)
LAN Port (s)	– Gigabit LAN 10/100/1000 Mb/s – Giga PHY Intel I219V – Supports Wake-On-LAN – Supports Lightning/ESD Protection – Supports Energy Efficient Ethernet 802.3az – Supports PXE
Supported Storage	– 4 x SATA3 6.0 Gb/s Connectors* – 1 x Hyper M.2 Socket (M2_1), supports M Key type 2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (Socket M2_1 works with 11th Gen Intel Core processors only) – 1 x Ultra M.2 Socket (M2_2), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
Audio	– 7.1 CH HD Audio (Realtek ALC897 Audio Codec) – Supports Surge Protection – Nahimic Audio
Internal I/O Ports	– 1 x Chassis Intrusion and Speaker Header – 2 x RGB LED Headers – 2 x Addressable LED Headers – 1 x CPU Fan Connector (4-pin) – 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) – 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) – 1 x 24 pin ATX Power Connector – 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) – 1 x 4 pin 12V Power Connector (Hi-Density Power Connector) – 1 x Front Panel Audio Connector – 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card) – 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) – 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)
TPM (Trusted Platform Module )	– 1 x SPI TPM Header
Warranty Information
Manufacturing Warranty	03 years warranty
